Individual hose record
4308037 Hose Repair Specifications
Excavator · Hitachi · EX400LC-3 · Hydraulic Pump
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4308037 before removing the hose.
Repair specifications
- Part number
- 4308037
- Diagram pipe number
- 2
- Installation route
- 先导泵~吸油铁管
- Hose specification
- DN19;4层纤维-12;3.5MPa
- Finished length
- 400 mm
- Working pressure
- 3.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
