Individual hose record
4429426 Hose Repair Specifications
Excavator · Hitachi · ZX200F · Swivel Joint
Finished length1,850 mm
Locate this hose
Installation diagram — Pipe No. 19A
Locate Pipe No. 19A in the diagram, then confirm part number 4429426 before removing the hose.
Repair specifications
- Part number
- 4429426
- Diagram pipe number
- 19A
- Installation route
- 回转接头~回油铁管(液压油箱)
- Hose specification
- DN13;2SN-08;27.5MPa
- Finished length
- 1,850 mm
- Working pressure
- 27.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
