- Length
- 1,400 mm
- Specification
- DN6;1SN-04;22.5MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
Individual hose record
4677925 Hose Repair Specifications
Excavator · Hitachi · ZX85USB-3 · Swivel Joint
Finished length1,350 mm
Locate this hose
Installation diagram — Pipe No. 22
Locate Pipe No. 22 in the diagram, then confirm part number 4677925 before removing the hose.
Repair specifications
- Part number
- 4677925
- Diagram pipe number
- 22
- Installation route
- Swivel joint → travel motorOriginal Chinese: 回转接头~行走马达
- Hose specification
- DN12;4SP-8;28Mpa
- Finished length
- 1,350 mm
- Working pressure
- 28 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 1
Same system
Related Hoses
Diagram Pipe No. 16
4415081
Installation route: Swivel joint → travel motorOriginal Chinese: 回转接头~行走马达
- Length
- 1,400 mm
- Specification
- DN10;1SN-06;18MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Length
- 1,380 mm
- Specification
- DN13;4SP-08;41.5MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
