Individual hose record
4438251 Hose Repair Specifications
Excavator · Hitachi · ZX800 · Control Lever
Finished length2,750 mm
Locate this hose
Installation diagram — Pipe No. 5
Locate Pipe No. 5 in the diagram, then confirm part number 4438251 before removing the hose.
Repair specifications
- Part number
- 4438251
- Diagram pipe number
- 5
- Installation route
- 右手柄~中转接头
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 2,750 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
