Individual hose record
KHJ2309 Hose Repair Specifications
Excavator · Case · CX245D · Control Valve
Finished length550 mm
Locate this hose
Installation diagram — Pipe No. F31
Locate Pipe No. F31 in the diagram, then confirm part number KHJ2309 before removing the hose.
Repair specifications
- Part number
- KHJ2309
- Diagram pipe number
- F31
- Installation route
- 分配阀右前~分配阀右后
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 550 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
