Individual hose record
9265954 Hose Repair Specifications
Excavator · Hitachi · ZX220W-3 · Attachments
Finished length750 mm
Locate this hose
Installation diagram — Pipe No. 27
Locate Pipe No. 27 in the diagram, then confirm part number 9265954 before removing the hose.
Repair specifications
- Part number
- 9265954
- Diagram pipe number
- 27
- Installation route
- 回转接头~电磁阀(推土铲)
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 750 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
