Individual hose record
4269832 Hose Repair Specifications
Excavator · Hitachi · ZX370FLC-FE-6N · Hydraulic Tank
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 35
Locate Pipe No. 35 in the diagram, then confirm part number 4269832 before removing the hose.
Repair specifications
- Part number
- 4269832
- Diagram pipe number
- 35
- Installation route
- 液压油箱~电磁阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 400 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
