Individual hose record

4436255 Hose Repair Specifications

Excavator · Hitachi · ZX330LC · Supply and Return Valve

Finished length1,950 mm

Locate this hose

Installation diagram — Pipe No. 1

Locate Pipe No. 1 in the diagram, then confirm part number 4436255 before removing the hose.

Hitachi ZX330LC installation diagram showing hydraulic hose 4436255 at Pipe No. 1 — Hitachi ZX330LCPart 4436255 · Pipe No. 1Open full-size diagram

Repair specifications

Part number: 4436255
Diagram pipe number: 1
Installation route: 进回油阀~中转接头
Hose specification: DN10;1SN-06;18MPa
Finished length: 1,950 mm
Working pressure: 18 MPa
Left fitting: 美制内螺纹74°内锥
Right fitting: 90°美制内螺纹74°内锥
Quantity: 1
