Individual hose record
4369953 Hose Repair Specifications
Excavator · Hitachi · EX200LC-5 · Attachments – Breaker
Finished length640 mm
Locate this hose
Installation diagram — Pipe No. 15
Locate Pipe No. 15 in the diagram, then confirm part number 4369953 before removing the hose.
Repair specifications
- Part number
- 4369953
- Diagram pipe number
- 15
- Installation route
- 电磁阀(破碎器)~流速切换阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 640 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
