Individual hose record
4643029 Hose Repair Specifications
Excavator · Hitachi · ZX290LC-5G · Control Valve
Finished length550 mm
Locate this hose
Installation diagram — Pipe No. 6
Locate Pipe No. 6 in the diagram, then confirm part number 4643029 before removing the hose.
Repair specifications
- Part number
- 4643029
- Diagram pipe number
- 6
- Installation route
- 分配阀上~分配阀右
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 550 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 45°美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
