Individual hose record
KTJ12080 Hose Repair Specifications
Excavator · Case · CX750D RTC ME · Attachments
Finished length1,050 mm
Locate this hose
Installation diagram — Pipe No. L27-M27
Locate Pipe No. L27-M27 in the diagram, then confirm part number KTJ12080 before removing the hose.
Repair specifications
- Part number
- KTJ12080
- Diagram pipe number
- L27-M27
- Installation route
- 过渡阀块(散热器)~铁管(散热器)
- Hose specification
- DN19;2SN-12;21.5MPa
- Finished length
- 1,050 mm
- Working pressure
- 21.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
