Individual hose record
KHJ2238 Hose Repair Specifications
Excavator · Case · CX145D SR W/B · Attachments – Breaker
Finished length320 mm
Locate this hose
Installation diagram — Pipe No. Z35-F71
Locate Pipe No. Z35-F71 in the diagram, then confirm part number KHJ2238 before removing the hose.
Repair specifications
- Part number
- KHJ2238
- Diagram pipe number
- Z35-F71
- Installation route
- 破碎器踏板~电磁阀(破碎器踏板)
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 320 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
