- Length
- 1,030 mm
- Specification
- DN6;1SN-4;7Mpa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
Individual hose record
9159119 Hose Repair Specifications
Excavator · Hitachi · EX160LC-5 · Hydraulic Pump
Finished length1,030 mm
Locate this hose
Installation diagram — Pipe No. 9
Locate Pipe No. 9 in the diagram, then confirm part number 9159119 before removing the hose.
Repair specifications
- Part number
- 9159119
- Diagram pipe number
- 9
- Installation route
- 液压泵~电磁阀
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 1,030 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
