Individual hose record
4276438 Hose Repair Specifications
Excavator · Hitachi · EX120-5 · Grease Lines
Finished length2,200 mm
Locate this hose
Installation diagram — Pipe No. 8
Locate Pipe No. 8 in the diagram, then confirm part number 4276438 before removing the hose.
Repair specifications
- Part number
- 4276438
- Diagram pipe number
- 8
- Installation route
- Left boom-cylinder grease lineOriginal Chinese: 左大臂油缸黄油管
- Hose specification
- DN6;2层纤维-4;14MPa
- Finished length
- 2,200 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
