Individual hose record
4649438 Hose Repair Specifications
Excavator · Hitachi · ZX240LC-3 · Attachments – Lock Valve
Finished length3,650 mm
Locate this hose
Installation diagram — Pipe No. 1A
Locate Pipe No. 1A in the diagram, then confirm part number 4649438 before removing the hose.
Repair specifications
- Part number
- 4649438
- Diagram pipe number
- 1A
- Installation route
- 小臂油缸锁止阀~分配阀上
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 3,650 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
