Individual hose record
4343401 Hose Repair Specifications
Excavator · Hitachi · EX550LC · Supply and Return Valve
Finished length2,200 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4343401 before removing the hose.
Repair specifications
- Part number
- 4343401
- Diagram pipe number
- 2
- Installation route
- 进回油阀~过渡阀块(液压油箱)
- Hose specification
- DN10;1层纤维-6;14MPa
- Finished length
- 2,200 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
