Individual hose record

4213447 Hose Repair Specifications

Excavator · Hitachi · EX150 · Hydraulic Tank

Finished length1,550 mm

Locate this hose

Installation diagram — Pipe No. 8

Locate Pipe No. 8 in the diagram, then confirm part number 4213447 before removing the hose.

Hitachi EX150 installation diagram showing hydraulic hose 4213447 at Pipe No. 8 — Hitachi EX150Part 4213447 · Pipe No. 8Open full-size diagram

Repair specifications

Part number: 4213447
Diagram pipe number: 8
Installation route: 液压油箱~进回油阀
Hose specification: DN10;1层纤维-6;14MPa
Finished length: 1,550 mm
Working pressure: 14 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 90°美制内螺纹37°内锥
Quantity: 1
