Individual hose record
4207346 Hose Repair Specifications
Excavator · Hitachi · EX400LC · Hydraulic Pump
Finished length1,800 mm
Locate this hose
Installation diagram — Pipe No. 38
Locate Pipe No. 38 in the diagram, then confirm part number 4207346 before removing the hose.
Repair specifications
- Part number
- 4207346
- Diagram pipe number
- 38
- Installation route
- 液压泵~过渡阀块(隔板)
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 1,800 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
