Individual hose record
KHJ2310 Hose Repair Specifications
Excavator · Case · CX145D SR 2PB · Hydraulic Tank
Finished length1,350 mm
Locate this hose
Installation diagram — Pipe No. A20-B34
Locate Pipe No. A20-B34 in the diagram, then confirm part number KHJ2310 before removing the hose.
Repair specifications
- Part number
- KHJ2310
- Diagram pipe number
- A20-B34
- Installation route
- 液压油箱~电磁阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,350 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
