Individual hose record
FF532656 Hose Repair Specifications
Excavator · Hitachi · ZX130-6N · Attachments – Breaker
Finished length3,230 mm
Locate this hose
Installation diagram — Pipe No. 20
Locate Pipe No. 20 in the diagram, then confirm part number FF532656 before removing the hose.
Repair specifications
- Part number
- FF532656
- Diagram pipe number
- 20
- Installation route
- 控制阀(破碎器)~进回油阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 3,230 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
