Individual hose record
4662576 Hose Repair Specifications
Excavator · Hitachi · ZX225US-3 · Swing Motor
Finished length1,950 mm
Locate this hose
Installation diagram — Pipe No. 22A
Locate Pipe No. 22A in the diagram, then confirm part number 4662576 before removing the hose.
Repair specifications
- Part number
- 4662576
- Diagram pipe number
- 22A
- Installation route
- 回转马达~中转接头
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 1,950 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
