Individual hose record
4486003 Hose Repair Specifications
Excavator · Hitachi · ZX75US-5N · Pedal
Finished length650 mm
Locate this hose
Installation diagram — Pipe No. 16
Locate Pipe No. 16 in the diagram, then confirm part number 4486003 before removing the hose.
Repair specifications
- Part number
- 4486003
- Diagram pipe number
- 16
- Installation route
- 行走推杆~进回油阀
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 650 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
