Individual hose record

KHJ2312 Hose Repair Specifications

Excavator · Case · CX90D · Control Valve

Finished length2,500 mm

Locate this hose

Installation diagram — Pipe No. B10-K7

Locate Pipe No. B10-K7 in the diagram, then confirm part number KHJ2312 before removing the hose.

Part number: KHJ2312
Diagram pipe number: B10-K7
Installation route: 分配阀左~缓冲阀
Hose specification: DN6;1SN-04;22.5MPa
Finished length: 2,500 mm
Working pressure: 22.5 MPa
Left fitting: British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
Right fitting: British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
Quantity: 1

Same system

Diagram Pipe No. 14

Installation route: 分配阀左~铁管

Length: 800 mm
Specification: DN6;1SN-04;22.5MPa
Left fitting: British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
Right fitting: 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥

Diagram Pipe No. 17

Installation route: 分配阀左~分配阀左

Length: 320 mm
Specification: DN6;1SN-04;22.5MPa
Left fitting: British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
Right fitting: 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
