- Length
- 600 mm
- Specification
- DN10;1SN-06;18MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
Individual hose record
4420423 Hose Repair Specifications
Excavator · Hitachi · ZX225USLC · Hydraulic Pump
Finished length500 mm
Locate this hose
Installation diagram — Pipe No. 6
Locate Pipe No. 6 in the diagram, then confirm part number 4420423 before removing the hose.
Repair specifications
- Part number
- 4420423
- Diagram pipe number
- 6
- Installation route
- 液压泵~先导滤芯
- Hose specification
- DN12;1SN-8;7Mpa
- Finished length
- 500 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
