Individual hose record
4448927 Hose Repair Specifications
Excavator · Hitachi · ZX225USLC · Hydraulic Tank
Finished length1,900 mm
Locate this hose
Installation diagram — Pipe No. 27A
Locate Pipe No. 27A in the diagram, then confirm part number 4448927 before removing the hose.
Repair specifications
- Part number
- 4448927
- Diagram pipe number
- 27A
- Installation route
- 回油铁管(液压油箱)~先导滤芯
- Hose specification
- DN12;1SN-8;7MPa
- Finished length
- 1,900 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
