Individual hose record
4655642 Hose Repair Specifications
Excavator · Hitachi · ZX190W-3 · Control Valve
Finished length1,500 mm
Locate this hose
Installation diagram — Pipe No. 20A
Locate Pipe No. 20A in the diagram, then confirm part number 4655642 before removing the hose.
Repair specifications
- Part number
- 4655642
- Diagram pipe number
- 20A
- Installation route
- 分配阀左前~铁管(回转马达)
- Hose specification
- DN19;4SP-12;34.5Mpa
- Finished length
- 1,500 mm
- Working pressure
- 34.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° light-series flangeOriginal Chinese: 90°法兰-轻型
- Quantity
- 1
