Individual hose record
KBJ2809 Hose Repair Specifications
Excavator · Case · CX210 · Hydraulic Pump
Finished length450 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number KBJ2809 before removing the hose.
Repair specifications
- Part number
- KBJ2809
- Diagram pipe number
- 3
- Installation route
- 液压泵~液压油箱
- Hose specification
- DN19;2SN-12;21.5MPa
- Finished length
- 450 mm
- Working pressure
- 21.5 MPa
- Left fitting
- 英制外螺纹平面密封
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Quantity
- 1
