Individual hose record
4388835 Hose Repair Specifications
Excavator · Hitachi · ZX85USB-3 · Boom Assembly
Finished length750 mm
Locate this hose
Installation diagram — Pipe No. 12
Locate Pipe No. 12 in the diagram, then confirm part number 4388835 before removing the hose.
Repair specifications
- Part number
- 4388835
- Diagram pipe number
- 12
- Installation route
- Arm cylinder — leftOriginal Chinese: 小臂油缸左
- Hose specification
- DN13;4SP-08;41.5MPa
- Finished length
- 750 mm
- Working pressure
- 41.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
