Individual hose record
4451995 Hose Repair Specifications
Excavator · Hitachi · ZX270LC-3 · Attachments
Finished length350 mm
Locate this hose
Installation diagram — Pipe No. 40
Locate Pipe No. 40 in the diagram, then confirm part number 4451995 before removing the hose.
Repair specifications
- Part number
- 4451995
- Diagram pipe number
- 40
- Installation route
- 控制阀(辅助)~过渡阀块(辅助)
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 350 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
