Individual hose record
4634381 Hose Repair Specifications
Excavator · Hitachi · ZX870LC-5A · Control Lever
Finished length1,600 mm
Locate this hose
Installation diagram — Pipe No. 7
Locate Pipe No. 7 in the diagram, then confirm part number 4634381 before removing the hose.
Repair specifications
- Part number
- 4634381
- Diagram pipe number
- 7
- Installation route
- 中转接头~电磁阀(液压油箱)
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 1,600 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
