Individual hose record
4407364 Hose Repair Specifications
Excavator · Hitachi · ZX330LC · Grease Lines
Finished length3,400 mm
Locate this hose
Installation diagram — Pipe No. 23
Locate Pipe No. 23 in the diagram, then confirm part number 4407364 before removing the hose.
Repair specifications
- Part number
- 4407364
- Diagram pipe number
- 23
- Installation route
- Right boom-cylinder grease lineOriginal Chinese: 右大臂油缸黄油管
- Hose specification
- DN5;2层纤维-3;14MPa
- Finished length
- 3,400 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 公制卡套式
- Quantity
- 1
