Individual hose record
4299085 Hose Repair Specifications
Excavator · Hitachi · EX400LC-3C · Control Lever
Finished length1,250 mm
Locate this hose
Installation diagram — Pipe No. 33
Locate Pipe No. 33 in the diagram, then confirm part number 4299085 before removing the hose.
Repair specifications
- Part number
- 4299085
- Diagram pipe number
- 33
- Installation route
- 左手柄~进回油阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 1,250 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
