Individual hose record
4436293 Hose Repair Specifications
Excavator · Hitachi · ZX135US · Hydraulic Pump
Finished length500 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number 4436293 before removing the hose.
Repair specifications
- Part number
- 4436293
- Diagram pipe number
- 3
- Installation route
- 液压泵~先导滤芯
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 500 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
