- Length
- 3,200 mm
- Specification
- DN10;1层纤维-6;14MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
Individual hose record
4632363 Hose Repair Specifications
Excavator · Hitachi · ZX225USLC-3 · Supply and Return Valve
Finished length3,200 mm
Locate this hose
Installation diagram — Pipe No. 12A
Locate Pipe No. 12A in the diagram, then confirm part number 4632363 before removing the hose.
Repair specifications
- Part number
- 4632363
- Diagram pipe number
- 12A
- Installation route
- 进回油阀~中转接头
- Hose specification
- DN10;1层纤维-6;14MPa
- Finished length
- 3,200 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
