Individual hose record

4353626 Hose Repair Specifications

Excavator · Hitachi · EX550LC · Grease Lines

Finished length10,000 mm

Locate this hose

Installation diagram — Pipe No. 8

Locate Pipe No. 8 in the diagram, then confirm part number 4353626 before removing the hose.

Hitachi EX550LC installation diagram showing hydraulic hose 4353626 at Pipe No. 8 — Hitachi EX550LCPart 4353626 · Pipe No. 8Open full-size diagram

Repair specifications

Part number: 4353626
Diagram pipe number: 8
Installation route: 黄油软管卷盘~黄油枪
Hose specification: DN10;2SN-06;21Mpa
Finished length: 10,000 mm
Working pressure: 21 MPa
Left fitting: 英制外螺纹30°内锥
Right fitting: 英制外螺纹30°内锥
Quantity: 1
