Individual hose record
4304409 Hose Repair Specifications
Excavator · Hitachi · EX400LC-3 · Control Lever
Finished length1,600 mm
Locate this hose
Installation diagram — Pipe No. 11
Locate Pipe No. 11 in the diagram, then confirm part number 4304409 before removing the hose.
Repair specifications
- Part number
- 4304409
- Diagram pipe number
- 11
- Installation route
- 右手柄~中转接头(手柄)
- Hose specification
- DN10;1SN-06;7Mpa
- Finished length
- 1,600 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
