Individual hose record
730502002107 Hose Repair Specifications
Excavator · Sunward · SWE150W · Hydraulic Pump
Finished length430 mm
Locate this hose
Installation diagram — Pipe No. 13
Locate Pipe No. 13 in the diagram, then confirm part number 730502002107 before removing the hose.
Repair specifications
- Part number
- 730502002107
- Diagram pipe number
- 13
- Installation route
- 液压泵PSV~冲液器O
- Hose specification
- DN8;1SN-05;22.5MPa
- Finished length
- 430 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 公制内螺纹24°锥带O形圈-轻型
- Right fitting
- 90°公制内螺纹24°锥带O形圈-轻型
- Quantity
- 1
