Individual hose record
4664649 Hose Repair Specifications
Excavator · Hitachi · ZX190W-3 · Solenoid Valve
Finished length3,250 mm
Locate this hose
Installation diagram — Pipe No. 11A
Locate Pipe No. 11A in the diagram, then confirm part number 4664649 before removing the hose.
Repair specifications
- Part number
- 4664649
- Diagram pipe number
- 11A
- Installation route
- 电磁阀(隔板)~中转接头
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 3,250 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
