Individual hose record

4227083 Hose Repair Specifications

Excavator · Hitachi · ZX135US · Grease Lines

Finished length340 mm

Locate this hose

Installation diagram — Pipe No. 1

Locate Pipe No. 1 in the diagram, then confirm part number 4227083 before removing the hose.

Hitachi ZX135US installation diagram showing hydraulic hose 4227083 at Pipe No. 1 — Hitachi ZX135USPart 4227083 · Pipe No. 1Open full-size diagram

Repair specifications

Part number: 4227083
Diagram pipe number: 1
Installation route: Arm-cylinder grease lineOriginal Chinese: 小臂油缸黄油管
Hose specification: DN6;2层纤维-4;14MPa
Finished length: 340 mm
Working pressure: 14 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 90°美制内螺纹37°内锥
Quantity: 1
