Individual hose record
4643671 Hose Repair Specifications
Excavator · Hitachi · ZX160LC-5N · Swivel Joint
Finished length1,800 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4643671 before removing the hose.
Repair specifications
- Part number
- 4643671
- Diagram pipe number
- 1
- Installation route
- Swivel joint → travel motorOriginal Chinese: 回转接头~行走马达
- Hose specification
- DN19;4SP-12;35Mpa
- Finished length
- 1,800 mm
- Working pressure
- 35 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 2
