- Length
- 530 mm
- Specification
- DN6;1SN-04;22.5MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
Individual hose record
DS2093193 Hose Repair Specifications
Excavator · Doosan · DX35Z · Hydraulic Pump
Finished length1,050 mm
Locate this hose
Installation diagram — Pipe No. 41
Locate Pipe No. 41 in the diagram, then confirm part number DS2093193 before removing the hose.
Repair specifications
- Part number
- DS2093193
- Diagram pipe number
- 41
- Installation route
- 液压泵PB2口~回转马达PB口
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 1,050 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
