Individual hose record

4663552 Hose Repair Specifications

Excavator · Hitachi · ZX350LC-3 · Attachments – Breaker

Finished length1,800 mm

Locate this hose

Installation diagram — Pipe No. 61A

Locate Pipe No. 61A in the diagram, then confirm part number 4663552 before removing the hose.

Hitachi ZX350LC-3 installation diagram showing hydraulic hose 4663552 at Pipe No. 61A — **Hitachi ZX350LC-3**Part 4663552 · Pipe No. 61AOpen full-size diagram

Repair specifications

Part number: 4663552
Diagram pipe number: 61A
Installation route: 电磁阀(破碎器)~过渡阀块(破碎器)
Hose specification: DN6;1SN-4;7Mpa
Finished length: 1,800 mm
Working pressure: 7 MPa
Left fitting: 美制内螺纹37°内锥
Right fitting: 美制内螺纹37°内锥
Quantity: 2
