- Length
- 1,600 mm
- Specification
- DN10;1SN-06;18MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
Individual hose record
KHJ2239 Hose Repair Specifications
Excavator · Case · CX350D LC · Solenoid Valve
Finished length520 mm
Locate this hose
Installation diagram — Pipe No. G20-I20
Locate Pipe No. G20-I20 in the diagram, then confirm part number KHJ2239 before removing the hose.
Repair specifications
- Part number
- KHJ2239
- Diagram pipe number
- G20-I20
- Installation route
- 电磁阀(分配阀)~液压油箱过渡阀块
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 520 mm
- Working pressure
- 22.5 MPa
- Left fitting
- British female thread, 60° external cone seatOriginal Chinese: 英制内螺纹60°外锥
- Right fitting
- 90° elbow, British female thread, 60° external cone seatOriginal Chinese: 90°英制内螺纹60°外锥
- Quantity
- 1
