Individual hose record
4375908 Hose Repair Specifications
Excavator · Hitachi · EX750-5 · Control Lever
Finished length2,750 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4375908 before removing the hose.
Repair specifications
- Part number
- 4375908
- Diagram pipe number
- 2
- Installation route
- 中转接头(手柄)~接线板(遮蔽板)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,750 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制外螺纹37°外锥
- Quantity
- 1
