Individual hose record
4254443 Hose Repair Specifications
Excavator · Hitachi · EX400LC · Attachments
Finished length750 mm
Locate this hose
Installation diagram — Pipe No. 79
Locate Pipe No. 79 in the diagram, then confirm part number 4254443 before removing the hose.
Repair specifications
- Part number
- 4254443
- Diagram pipe number
- 79
- Installation route
- 左踏板~过渡阀块(踏板)
- Hose specification
- DN10;1层纤维-6;14MPa
- Finished length
- 750 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
