Individual hose record
DS2093664 Hose Repair Specifications
Excavator · Doosan · DX60R · Attachments – Lock Valve
Finished length3,200 mm
Locate this hose
Installation diagram — Pipe No. 4
Locate Pipe No. 4 in the diagram, then confirm part number DS2093664 before removing the hose.
Repair specifications
- Part number
- DS2093664
- Diagram pipe number
- 4
- Installation route
- 大臂油缸锁止阀PI1口~分配阀PI1口
- Hose specification
- -
- Finished length
- 3,200 mm
- Left fitting
- Female threadOriginal Chinese: 内螺纹
- Right fitting
- 90° elbow, female threadOriginal Chinese: 90°内螺纹
- Quantity
- 1
