Individual hose record
4387236 Hose Repair Specifications
Excavator · Hitachi · EX750-5 · Control Lever
Finished length1,650 mm
Locate this hose
Installation diagram — Pipe No. 8
Locate Pipe No. 8 in the diagram, then confirm part number 4387236 before removing the hose.
Repair specifications
- Part number
- 4387236
- Diagram pipe number
- 8
- Installation route
- 左手柄~中转接头(手柄)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 1,650 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
