Individual hose record
4630725 Hose Repair Specifications
Excavator · Hitachi · ZX850LC-3 · Grease Lines
Finished length1,750 mm
Locate this hose
Installation diagram — Pipe No. 1A
Locate Pipe No. 1A in the diagram, then confirm part number 4630725 before removing the hose.
Repair specifications
- Part number
- 4630725
- Diagram pipe number
- 1A
- Installation route
- 分流阀(黄油)~过渡阀块(黄油)
- Hose specification
- DN6;1SN-4;10.5MPa
- Finished length
- 1,750 mm
- Working pressure
- 10.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 公制卡套式
- Quantity
- 1
