Individual hose record
4285785 Hose Repair Specifications
Excavator · Hitachi · EX100M-3 · Solenoid Valve
Finished length700 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number 4285785 before removing the hose.
Repair specifications
- Part number
- 4285785
- Diagram pipe number
- 3
- Installation route
- 电磁阀~回油铁管(液压油箱)
- Hose specification
- DN12;1层纤维-8;10.5MPa
- Finished length
- 700 mm
- Working pressure
- 10.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
