Individual hose record
4650222 Hose Repair Specifications
Excavator · Hitachi · ZX210W-3 · Hydraulic Pump
Finished length980 mm
Locate this hose
Installation diagram — Pipe No. 3
Locate Pipe No. 3 in the diagram, then confirm part number 4650222 before removing the hose.
Repair specifications
- Part number
- 4650222
- Diagram pipe number
- 3
- Installation route
- 液压泵~分配阀(进油)
- Hose specification
- DN22;4SP-14;35Mpa
- Finished length
- 980 mm
- Working pressure
- 35 MPa
- Left fitting
- 90° heavy-series flangeOriginal Chinese: 90°法兰-重型
- Right fitting
- 90° heavy-series flangeOriginal Chinese: 90°法兰-重型
- Quantity
- 1
